Your Advantages

• Two-dimensional beam deflection allows standalone operation or integration into production lines (axis, roll-to-roll)

• Synchronization of two scanners on one laser source (optional)

• Wide range of applications: laser marking, microstructuring, surface cleaning, drilling, cutting, spot welding, engraving (2.5D), and more

Technical Details

• Dimensions: 170 × 140 × 135 mm

• Weight: < 10 kg

• Clear Aperture: 10 mm

• Max Lines/s: 666 Hz @ 5,000 rpm (8F) / 1,000 Hz @ 5,000 rpm (12F)

• Power Supply: 24–48 V DC, max. 150 W

• Interfaces: 1× Gbit Ethernet, digital Laser I/O, analog I/O, GPIO / Axis I/O

• FPGA On-board Processing, On-board Memory 1–2 GByte
